Guideline 1 - Support Structure
For mounting an uneven surface, four support structures can be implemented in the 3D-file. These will be calculated together with the rest of the model to achieve an even surface.
Guideline 2 - Two Parts in One File
To save on costs, smaller pieces can be produced together. For this, they have to be aligned horizontally in the corresponding step file.
Guideline 3 - Offset
An offset of minimum 10 mm is necessary to avoid surface defects in the final contour. With an offset of exactly 10 mm the part needs to be mounted very precisely for milling. For higher tolerances, a bigger offset is recommended.
Guideline 4 - Alignment
In case the model is not aligned alongside at least one plane in the building space, this needs to be done to produce an even surface. If the model is already aligned, this step can be skipped.
Guideline 5 - Reinforcing Ribs
When designing reinforcing ribs < 50 mm in the original 3D-model, ribs with 50 or 100 mm will appear in the CUBES-model. The smaller these designed structures are, the higher will be the probability of getting only 50 mm ribs.
ORDER SAMPLE FOR MATERIAL TESTING
Please fill out the form below and submit it. You will receive a confirmation via email.
You are already registerd or want to register for future orders?
Price per Litre: 8.56 €
Price Total: 1,712.00 €
Download of Datasheet
The exact material properties are as individual as the produced parts. The table below gives an overview of what is possible. Adapting one parameter leads to automatic calculation of the other values as well:
Hardness (67-86) [Shore D]:
Tensile Strength (12-21) [MPa]:
Bending Strength (16-41) [MPa]:
E-Modulus (578-5599) [MPa]:
Compressive Strength (22-39) [MPa]:
Density (0.75-1.78) [kg/L]:
Resulting Physical Properties:
Tensile Strain [%]:
Bending Strain [%]:
Heat Resistance (TG) [°C]:
Coefficient of Expansion αT:
