Tool for price calculation - direct cast: We cast our CUBES PU material (up to 2,000 liters) into your very own form made of styrofoam, wood or metal.

Please use our tool beneath for price calculation: Just enter volume and concentration of your desired contour. All total prices include € 95 of setup costs.

Price per Litre: 10.41 €

Price Total: 2,177.00 €

If you are interessted, please contact us via e-mail:

Ing. Bernhard Volgger, MBA - CEOTel: +43 664 5143011E: bernhard.volgger@cubes-gmbh.com

GUIDELINES

Guideline 1 - Support Structure

For mounting an uneven surface, four support structures can be implemented in the 3D-file. These will be calculated together with the rest of the model to achieve an even surface.

Guideline 2 - Two Parts in One File

To save on costs, smaller pieces can be produced together. For this, they have to be aligned horizontally in the corresponding step file.

Guideline 3 - Offset

An offset of minimum 10 mm is necessary to avoid surface defects in the final contour. With an offset of exactly 10 mm the part needs to be mounted very precisely for milling. For higher tolerances, a bigger offset is recommended.

Guideline 4 - Alignment

In case the model is not aligned alongside at least one plane in the building space, this needs to be done to produce an even surface. If the model is already aligned, this step can be skipped.

Guideline 5 - Reinforcing Ribs

When designing reinforcing ribs < 50 mm in the original 3D-model, ribs with 50 or 100 mm will appear in the CUBES-model. The smaller these designed structures are, the higher will be the probability of getting only 50 mm ribs.
